Fusion Cut

Rib &
Brisket Saw

FUSION CUT

Rib and Brisket Saw

St. Louis Style Rib Cutting Solution

Suitable for large meat processors looking to cut St. Louis style ribs and briskets.

Request A Quote Download Catalog

Equipment Overview

Quickly cut St. Louis Style ribs and briskets.

Make quick work of cutting St. Louis style ribs and briskets with our innovative Rib and Brisket Saw.

Engineered to cut through cartilage and hard bone, this saw is safe, ergonomic, and cost-effective.

An adjustable rib guide attached to the main feed belt conveyor allows for 4” – 6” cuts and can be adjusted easily by the operator. Dual cutting lanes with laser light guides give you greater output and more consistent cuts than cutting by hand or band saw. Hold down belts keep ribs in place during the cutting process.

Safety is key in the meat processing industry. The Rib and Brisket Saw boasts a safety stop bar to kill power to the machine, safety guarding with latch locks to prevent the machine from starting if guarding is not correctly secured, and two emergency stop buttons on the machine and one on the control panel.

Construction

  • Stainless steel type 304 construction
  • All seams fully seal welded
  • Open conveyor frame for easy cleaning
  • 18” serrated, single bevel blade with removable guarding and top port to wash abscess
  • Robust design

Safety

  • Safety stop bar on infeed stops the machine when touched
  • Safety lockout late prevents machine from operating if guarding is not correctly secured
  • Safety guarding around the cutting area protects operators from injury

Cleaning / Sanitation

  • Wash down components allow for high pressure washing
  • Exceeds all AMI Sanitary Design requirements

View The Technical Specs

Download the catalog to learn more about our rib and brisket saw.

Download Catalog

Equipment Videos

Rib & Brisket Saw

Rib & Brisket Saw

Rib & Brisket Saw

Technical Specs

Product

Ribs

Cut Adjustability

4″-6″

Electrical

230/460 VAC / 60 Hz / 2.9/1.5 Amps

To Control Box

480 VAC / 30 Amps

Conveyor Motors Drive Shaft

1 HP

Saw Motors Drive Shaft

2 HP

Blade Diameter

18″ Serrated

Belt Width

36″

TOB Height

45.75″

Length

97.36″

Width

74.59″

Height

80.21″

Weight

3,366.39 lbs

Cut St. Louis style ribs and briskets.
