Model Number
A-06323
Infeed Height
40.16″
Discharge Height
40.16″
Belt Width
22″
Inverter Duty Motor
1/2 HP, 3 phase
Fusion Process
Belly
Roller
FUSION PROCESS
Belly Roller
Pork Belly Flattening Solutions
Suitable for large meat processors looking to flatten pork bellies prior to further processing.
Equipment Overview
Quickly flatten pork bellies prior to further processing.
Make quick work of flattening pork bellies with our belly roller conveyor.
Engineered to provide a uniform and symmetrical flattening of meat prior to further processing, the belly roller is a must-have addition for any bacon processing line.
The unique design of this belly roller allows operators to visually inspect the bellies as they enter the roller while keeping them safe from dangerous pinch and smash points.
Our belly roller meets all AMI sanitary design guidelines.
Improve your pork belly processing line with our belly roller conveyor!
Construction
- Stainless Steel Type 304 Construction
- All Seams Fully Seal Welded
- Robust Design
- 22″ Stainless Steel Roller
- Intralox S800 flat top, open hinge, seam free, 22”, white acetal belt
Safety
- Safety sensors located on conveyor guarding verify safety cage over roller is securely closed.
Cleaning / Sanitation
- Hinged doors make cleaning the machine easy
- Wash down components allow for high pressure washing
- Exceeds all AMI Sanitary Design Requirements
Download the catalog to learn more about our belly roller.
Technical Specs
Roller Width
22″
Length
110.71″
Width
54.73″
Height
67.98″
Weight
1,621.11 lbs
