Sanitary Conveyors

Custom Material Handling Solutions

Sanitary Design Requirements. Exceeded.

We take sanitary design seriously — and design our conveyors to exceed all AMI Sanitary Design Requirements to keep your food product safe.

metal detector conveyor rendering
z conveyor

Conveyors. Custom Designed to Fit Your Need.

Our conveyors are custom designed with options and features to meet the needs of your specific application. 3D models allow you to see our solution before fabrication begins.

Download the Fusion Move catalog to learn more about our sanitary conveyors.

Sanitary Design

Our conveyors exceed all AMI Sanitary Design Requirements making them safe to use in meat and food processing facilities.

Easy to Clean

Our conveyors boast wash down components and add on features making them the easiest to clean on the market.

Custom Designed

Our conveyors are custom designed to meet the needs of your specific application.

Standard Features

3D Modeling and Design

  • Approval Drawings & 3D Models
  • Detailed drawings for easy re-order
  • Spare parts list provided

Construction

  • Stainless Steel Type 304 Construction
  • Captured machined UHMW carryway rails eliminate accidental misplacement or loss of carryways
  • Stainless steel return shafts chrome plated for wear resistance with UHMW return roller
  • Food grade belting and components (modular and one piece)
  • Adjustable foot pads or casters
  • Frames built of either stainless steel angle iron or formed sheet metal

Food Safety & Sanitation

  • 100% cleanability
  • Continuous TIG welds prevent bacteria from harboring and growing in niches
  • Horizontal surfaces minimized
  • Angles turned in such a way to prevent voids facing down, flat surfaces, or harborage areas
  • Exceeds AMI Sanitary Design Requirements

Options

Frame Options

  • Formed Sheet Metal
  • Angle Iron

Mounting Options

  • Ceiling
  • Floor — choose one:
    • Rigid
    • Swivel
    • Caster

Finish Options

  • Glass Bead Blast
  • 2B Stainless Finish
  • DA Stainless Finish

Belt Options

  • Can Washing
  • Cleated
  • Fabric
  • Metal
  • Metal Mesh
  • Metal/Plastic (Hybrid)
  • Plastic
  • Plastic Coated
  • Plastic Mesh
  • Roller Chain
  • Rubber & Rubber Compounds
  • Seamless
  • Steel Band
  • Wire

Intralox Activated Roller Belt™ Techology

Fusion Tech is one of very few Intralox ARBTM Licensed Sellers in the Midwest. Intralox’s Activated Roller Belt™ technology is a patented conveyance solution that brings the benefits of modular plastic belting to complex package handling processes like sorting, merging, and aligning. The result is an automated conveyance platform that enables critical improvements where it was previously cost-prohibitive or overly complex. ARB technology is a reinvention of the way packages move from point A to point B, proven in over 4,000 installations worldwide.

Applications Include:

  • 90-Degree Transfers
  • Aligners
  • Case Turners
  • Depalletizing Systems
  • Merges
  • Palletizing Infeed Systems
  • Singulators
  • Sortation Systems
  • Switches

Sanitary Design

tig welds

TIG Welds

Prevents bacteria from harboring in weldment areas.

stand offs

Stand-Offs & Spacers

Prevents metal-on-metal bacteria harboring points.

pivoting carryways

Pivoting Captured Carryways

Easily clean the bottom side of carryways without losing or misplacing them.

toolless belt removal

Tool-less Belt Removal

Remove belt for cleaning and maintenance without the need for special tools.

fasteners

Minimized Fastener Use

Cuts down on places where bacteria can harbor.

channel frame

Under Bent Channel Frame

Formed channels are under bent to eliminate flat spots for water and product to sit on.

angle frame

Angle Frame

Open architecture eliminates bacteria harboring points found in enclosed tubing.

Add On Features

1
conveyors belt lifters
1

Belt Lifters

Lift conveyor belt without removing it for easy cleaning and sanitation.

Belt Lifters

1
1

Belt Scrapers

Cleans off stuck on food product and pieces while in operation.

Belt Scrapers

1
conveyor drip pans
1

Drip Pans

Prevents product dropped off of belt from falling onto platforms or equipment below.

Drip Pans

1
1

Spray Bars

Attach a hose to easily clean under belt and inside conveyor without needing to remove the belt.

Spray Bars

1
conveyor guide rails
1

Guide Rails

Easily direct product where you want it go on the belt with UMHW guide rails.

Guide Rails

1
casters to footpads
1

Casters to Footpads

Quickly and easily switch from casters for mobility to footpads for stability.

Casters to Footpads

1
1

Pivoting Ends

Conveyor end can be pivoted up to allow for employee egress in tight spaces.

Pivoting Ends

1
1

Ergonomic Stands

Attach an adjustable ergonomic stand to the side of your conveyor, or purchase a stand-alone model to place next to your conveyor. See all of our ergonomic stands.

Ergonomic Stands

Download the Fusion Move catalog to learn more about our sanitary conveyors.

Applications

  • Raw Product Conveyors
  • Ready-to-Eat Conveyors
  • Packaging Conveyors
  • Metal Detection Conveyors

Styles

  • Flighted
  • Scoop
  • ARB™ Technology
  • Zero Tangent
  • Modular
  • Seam Free
  • Chain
  • Band
  • Wire

Food Industries

Our conveyors are designed for use over a number of food processing and packaging industries:

  • Meat & Poultry
  • Bakery
  • Produce
  • Ingredients
  • Pet Food

Packaging Conveyors

Press Conveyors

Quickly flatten and tenderize fresh or chilled meat with minimal loss of purge or weight, preparing your product for further processing.

Screw (Auger) Conveyors

Convey bulk materials ranging from large pellets to sub-micron powders with no separation of blending products.

Bacon (Belly) Conveyors

Process pork bellies for the production of bacon with these conveyors specifically designed for bacon processors.

Specialty Conveyors

Download the Fusion Move catalog to learn more about our sanitary conveyors.
